EDX8800E absorbs all the advantages of EDX series and is additionally equipped with vacuum system, so that it expands testing scope, improves the detection limit and enhances the data stability.
Specifications
l Measurable elements: Na-U
l Element content: 1ppm-99.99%
l Detection limit: 1ppm
l Measurement time: 60-200s (adjustable)
l Power:AC220±5V
l Energy resolution: 129±5 eV
l X-ray tube maximum output current: 1mA
l Ultimate pressure:6.7×10-2 Pa
l Sample chamber size: 610*320*100(mm) (Without vacuum)/Φ100*h75(mm) (Vacuum)
l Long-time working stability(subject to standard sample):±0.05%(high content)
l /±0.002%(micro-content)
l Excellent repeatability(subject to standard sample):0.06%((high content)/±0.0025%(micro-content)
